Model

C1.86

LED encapsulation

SMD1515 black light

Pixel pitch

1.86mm

Resolution

288906 pixels/m²

Lamp bead/IC

Domestic copper wire/high fresh rate

Color configuration

1R1G1B

Module resolution

172*86

Module size (mm)

320*160

Module weight

0.36kg/pc

Power voltage

DC+4.2V~+5V

Main parameter

Best viewing distance

≥5.5m

Horizontal viewing angle

≥175°

Vertical viewing angle

≥175°

Maintenance method

Front maintenance

Graphics card

DVI/HDMI/DP

Video signal

Compatible with PAL/NTSC/SECAM format, support S-Video; VGA; RGB; CompositeVideo; SDI; DVI; RF; RGBHV; YUV; YC, etc.

Control mode

Synchronous control

Drive device

Constant current

Refresh rate

≥3840Hz

Frame rate

≥60Hz

Scanning method

58S

Brightness

200～600CD/m²

Grayscale

12/14/16bit

Contrast

≥10000:1

Attenuation rate (after 3-year work)

≤15%

Brightness adjustment

Auto/Manual: 1～100%

Computer operating system

WIN98/2000/WINXP/WINVista/WIN7

MTBF

≥20000H

Lifespan

≥100000H

Failed rate

≤1/100000 and no continuous failed pixels

Software

Professional LED display system programming software

Storage temperature

-35℃～+85℃

Working temperature

-20℃～+60℃

Working voltage (AC)

220V±10%/50Hz or 110V±10%/60Hz

Average power consumption

≤168W/m²

Maximum power consumption

≤500W/m²

Installation method

Magnetic attraction

Brightness uniformity

≥99%
